OK, as of March 04, I have had the player running for about a year, and for a long time I had some ideas about improving the player.

2 of the fans were a bit worn and was making unnessesary much noise. Those were replaces with brand-new low-noice types on 7 volts. The third I kept, but made it controlable with the potentiometer in front. That way I can regulate the fanspeed (and noise).

One of my other big wishes, was beeing able to record and view movies and shows from TV. Finally I bought an external USB tvcard, and now I can use my divxplayer as a VCR. The tvcard is a Hauppauge with build-in MPG2 compressor, that almost dosn't use any CPU power.

With the tvcard in place, the next thing I needed was more HD space, so I swapped the 6 GB with a 80 GB disk. And as I had the cover off, I desided to put in a Duron 750 Mhz CPU instead, because the 1300 Mhz was overkill for now (and besides, I could use the 1300 elsewhere).

Some time later I got myself a cute little 3x16 chars LCD display, that was able to fit in place of the original CDplayer one. I soldered it to a LPT port connecter and got it running with som software called jaLCDs. It now shows CPU power used, RAM used, and free space on drive C.

Click here for more pictures


    Hardware specs:
    • Case from a Sony CD player.
    • MSI MS6390L-LE motherboard with onboard Sound/LAN/VGA.
    • 750 MHz Duron CPU.
    • ATI RAGE 128 Videocard with tvout.
    • AGP Risercard AGPTX4-6B.
    • Standard 300W ATX PSU.
    • 52x Speed Aopen CDROM drive.
    • 80 GB Segate Harddisk.
    • 256 MB DDR Ram.
    • Hauppauge USB TVcard
    • Controllerprint from an old keyboard.
    • 2 x 40mm and 1 x 50mm fans.
    • 3 x 16 char LCD Display

    Software specs:
    • Windows XP Pro.
    • DivX, Xvid and SVCD codec's.
    • BSplayer to play all kinds of mediafiles.
    • WinLirc to connect the infra red reciever to BSplayer.
    • WinVNC to remote control the PC over the network.
    • Hauppauge software to record and view movies and TV shows.
    • jaLCDs to control the LCD display.

    Other info:
    • Additional build time: 10 hours.
    • Extra cost: $300.
